High Transmittance 3D Cinema Systems Laser Triple Beam 1:1 Throw Ratio Modulators

High Transmittance 3D Cinema Systems Laser Triple Beam 1:1 Throw Ratio Modulators

Product Details:

Place of Origin: SHENZHEN
Brand Name: HONY
Certification: CE,ROHS
Model Number: HONY3D-T-LASER1.1

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiable
Delivery Time: 3days
Get Best Price Contact Now

Detail Information

Transmittance: 75% Light Efficiency: 30%
Contrast Ratio: 150:1 Projection Distance: 7-32 Meters
Silver Screen Required: Gain 2.4 Or Above Polarization Type: Circular Polarized
High Light:

home cinema systems

,

3d cinema system

Product Description

High Transmittance 3D Cinema Systems Laser Triple Beam 1:1 Throw Ratio Modulators

High Transmittance 3D Passive Cinema system Laser Triple Beam 1:1 Throw Ratio



1:1 Throw Ratio Laser Triple Beam 3D system



High Transmittance 3D Cinema Systems Laser Triple Beam 1:1 Throw Ratio Modulators 0



HONY3D 1: 1 projection ratio laser triple beam 3D system, HONY3D-T-LASER1.1 set in one,

with Barco 6P laser projector DP4K-60L or Christie RGB laser projector Christie CP42LH,

become the most mature 3D solution for the flagship theater with giant screen laser movie hall.



High Transmittance 3D Cinema Systems Laser Triple Beam 1:1 Throw Ratio Modulators 1

HONY3D-T-LASER 1.1 combines the advantages of 1: 1 projection ratio 3D system HONY3D-T-1.1

and HONY3D-T-LASER RGB laser triple beam,

specifically optimized design for the reddish screen of low throw ratio movie hall with a laser source Presence of horizontal color stripes.

The projection ratio can support 0.95: 1 (depending on the lens parameters vary).



For more specification refer below table:

Model HONY3D-T-LASER1.1   2D /3D shift Auto
transmittance 74% Power Dissipation <12W
Light Efficiency 29% Power Supply 3D Interface(12V)
Contrast Ratio 100:1 Surface Hardness 9H
Throw Ratio 1.1 above Surface Treatment AR&AS
Projection Distance 12-35meters Polarization Type Circular Polarized
Pixel Coincide < 1 Pixel Silver Screen Required Gain 2.4 or above
Frame Rate Maximum 120 frame Projector Required Barco/Christie/NEC
support 60000 Lum
support 6P 9P laser projector
Resolution Ratio Support 4K
